The new Super B NOMIA battery is a powerful lithium iron phosphate battery (LiFePO4) for motorhomes, campers and caravans and suitable for 12 volt installations.
The supply battery, specially developed for motorhomes, can be connected to covernors with up to 6000 watts. The service life is up to 5000 cycles.
The integrated Battery Management System (BMS) and the Bluetooth functionality inform you around the clock about the state of the battery. The data can be displayed via App or LED display.
The compact design allows replacement with older lead-acid batteries.
The LiFePO4 battery is characterized by excellent weight reduction, enormous energy reserves and stable voltage even under extreme load. So air conditioner, coffee maker and hair dryer can be operated with peace of mind.
Capacity 210 Ah
Voltage 12.8 V
Dimensions (LxWxH) 417 x 227 x 314 mm
Net weight without packaging 23 kg
Product color black, green
TEMPERATURE SPECIFICATIONS
Charge temperature 0°C to 55°C / 32°F to 131°F
Discharge temperature -20°C to 55°C / -4°F to 131°F
Storage temperature -20°C to 45°C / -4°F to 113°F
CHARGE AND DISCHARGE SPECIFICATIONS
Charge method CCCV
Charge voltage 14, 3V - 14.6V
Max. Charge current 210A
Discharge voltage 10V
Max. Continuous discharge current 500A
Discharge pulse current 800A (10 sec)
CONFORMITY SPECIFICATIONS
Certifications CE, FCC, UN 38.3, UN ECE R10.06, UL 1642 (cells)
Transport classification UN 3480
